Anthem MRX 740 8k

Anthem MRX 740 8k

PREAMPLIFIER
Maximum Output (<0.1% THD) 5.2 VRMS, 7.1VRMS
Frequency Response 20Hz – 30KHz +/-0.2dB
Frequency Response, Analog-Direct N/A
THD+N (2 Vrms output) -100 dB
S/N Ratio (2 Vrms output, IEC-A filter) 110 dB
PREAMPLIFIER + AMPLIFIER (1 W OUTPUT)
MRX 1140 / MRX 740 SNR: 91 dB ch 1-5, 86dB others
MRX 540 SNR: 91 dB ch 1-5
SPEAKER IMPEDANCE
Compatible with 4 Ohms or higher impedance.
MAXIMUM CONTINUOUS OUTPUT (1% THD)
Channels 1-5, Two Driven into 8 Ohms  140 W
Channels 1-5, Two Driven into 6 Ohms 170 W
Remaining Channels, Two Driven into 8 Ohms 60 W
Remaining Channels, Two Driven into 6 Ohms 75 W
POWER CONSUMPTION
Typical Load 485 W
Standby 0.3 W
Standby IP Control Enabled 1.8 W
Standby HDMI Bypass Enabled 4.9 W
DIMENSIONS
Height (without feet) 6″ (15.24 cm)
Height with Rackmount Kit 4U
Width 17″ (43.18 cm)
Depth (including wifi ant not power cord) 14-1/2″ (36.4 cm)
WEIGHT
MRX 740 33.2 lb (15.1 Kg)
POWER REQUIREMENT
120 V version: In countries where the line voltage is 120 V, this product operates from a single phase AC power source that supplies between 108 V and 132 V at a frequency of 60 Hz.
220-240 V version: In countries where the line voltage is 220, 230, or 240 V, this product operates from a single phase AC power source that supplies between 198 V and 264 V at a frequency of 50 Hz.
