Product Description
JBL SMA 8300
|
Analog audio input 8x XLR (Balanced)
Digital audio input (Dante/AES67) 2x RJ45
Speaker output Binding Posts, accommodates 10AWG wire, spade and banana termination
12VDC trigger control1x 3.5mm (in), 1x 3.5mm (out)
Network/monitoring/control 1x RJ45
PowerStandard IEC
Power (2 channels driven, <0.5% THD), Rated Power (8Ω)300W
Power (2 channels driven, <0.5% THD), Rated Power (4Ω)600W
Power (2 channels driven, <0.5% THD), Rated Power (8Ω Bridged, one zone driven)1,200W
Digital signal processing 96kHz, 32-bit floating point
Frequency response (4Ω, 20Hz – 20kHz)±0.5dB
Total harmonic distortion (at full rated power, from 20Hz – 20kHz) 0.35%
Analog input signal to noise ratio (ref. Rated power, ‘a’-wtd.)>105dB
Analog input signal to noise ratio (ref. Rated power, 20Hz – 20kHz) >99dB
Damping factor (20Hz to 100Hz) >1000
Input impedance (nominally balanced, nominally unbalanced) 70 kΩ balanced, 35 kΩ unbalanced
Maximum input level (low amp gain mode) +21dBU
Load impedance stereo/dual mode 2Ω –16Ω load
Impedance bridge mono 4Ω – 16Ω
Maximum fan noise (REF. dB SPL @ 1M) 51dBA
Power supply 100 – 220V ±10%, 50/60Hz
Dimensions incl. rack ears, connectors, controls (H x W x D)3.5 x 19.0 x 17.0 in (88.9 x 482.6 x 432.6 mm)
Dimensions excl. rack ears, connectors, controls (H x W x D)3.5 x 17.0 x 15.7 in (88.9 x 431.8 x 400.0 mm)
Net Weight23.1 lb (10.5 kg)
|
