Moon 760A

34200 lei/bucata

Sau 4275 lei / luna in 8 rate

Garantie 24 luni

* Preţul conţine TVA şi taxa timbru verde
SKU: 12017. Category: . Tag: .

Descriere Produs
The MOON 760A is the first amplifier to be housed in the slim Evolution series chassis, making it unusually compact, yet very heavy. A dual-mono, class A/B design with balanced differential circuitry, it exhibits all the sonic hallmarks which MOON products are globally known for: an airy, detailed and open top end, transparent and 3-dimensional in the midrange, robust, powerful and authorative in the bass. In a nutshell, the 760A will amplify music with all the harmonic accuracy, richness and dimensionality of a live musical performance.

760A

Product Description

  • 760A Detailed Specifications
  • Type Solid State
  • Configuration Dual-Mono / Balanced
  • Power Supply Transformers 2 x 0.5kVA
  • Power Supply Capacitance 80,000µF
  • Class Of Operation A/AB
  • Balanced Inputs XLR – 1 pair
  • Single-ended Inputs RCA – 1 pair
  • Input Device Type J-FETs
  • Input Impedance 47.5KΩ
  • Input Sensitivity 900mV RMS
  • Output Device Type Bipolars – 4 per channel
  • Output Binding Posts WBT – 1 pair per channel
  • Output Power @ 8Ω 130 Watts
  • Output Power @ 4Ω 260 Watts
  • Output Power @ 2Ω 500 Watts
  • Output Power – Bridged Mono 500 Watts
  • Frequency Response 10Hz – 200kHz (+0/-3dB)
  • Output Impedance < 0.03Ω
  • Damping Factor (static) > 267
  • Gain 31dB
  • Signal-to-noise Ratio 104dB @ full power
  • Maximum Output Voltage 37 Volts
  • Slew Rate 35 V/µs
  • Maximum Current – Peak 32 amperes
  • Maximum Current – Continuous 20 amperes
  • Crosstalk @ 1kHz -102dB
  • IMD Unmeasureable
  • THD (20Hz – 20kHz @ 1 watt) 0.015 %
  • THD (20Hz – 20kHz @ 130 watts) 0.04 %
  • 12 Volt Trigger Input/Output Operation Direct Logic (0V = off, 12V=on) using a 3.5mm
    mono jack with an Input/Output impedance of
    1000Ω and current requirement of 12mA
  • RS-232 Port 9-pin female DB connector
  • Power Consumption @ idle 35 watts
  • AC Power Requirements 120V / 60Hz 220-240V / 50Hz
  • Fuse Replacement 120V / 220-240V 6.0A long fast blow / 3.0 long fast blow
  • Shipping weight 45 lbs / 20 kgs
  • Dimensions (w x h x d) 18.75 x 4.0 x 18.1 in. (47.6 x 10.2 x 46.0 cm.)
