Product Description
| Vacuum Tube Complement: | 2 x 12AU7, 4 x 12AT7 (line stage) 2 x 12X7, 2 x 12AX7 (Phono MM), 2 x 12AU7 (Phono MC) |
| Inputs: | 2 pair balanced/XLR or RCA single-ended 6 pairs single-ended/RCA |
| Outputs: | 1 pair balanced out 1 pair single-ended RCA out 1 pair single-ended RCA buffered Record Out |
| Remote control functions: | Power Source Select Volume up/down Mute Fade Balance Control Phase Reverse |
| Gain | Normal Gain –11 dB single ended, 17dB balanced Switchable to Low Gain – 6 dB SE,11 dB balanced Phono MM – 40dB Phono MC — Selectable 54dB, 60dB, 66dB |
| Output Impedance: | 150 Ohms (Max400 ohms at 10Hz) |
| Input Impedance : | 35K Ohms |
| Frequency response + 0 – 1 dB: |
1 Hz – 200 KHz + 0 – 1dB |
| Maximum Output Voltage < 1% THD: | 30 Volts 10Hz – 200kHz, 1.75V into 600 ohms at 1%THD |
| Channel Separation: | > 100 dB @ 1KHz (>80 dB @ 20kHz) |
| Power Consumption: | 60 Watts (Line Stage) 130 Watts (with Phono stage) |
| Weight and Dimensions: | 40 lbs (18.12 Kg) Fully packed in one box Unpacked weight: 30 lbs (13.6 Kg) |
